GX-D102
GX-D102
■Adopt Intel ? HM76 chipset
■Support for Intel ? 3rd generation Core ? i5 / i3 processors
■Support 7×USB2.0, 2×COM, 1× gigabit network card
■Support VGA+HDMI synchronous/asynchronous dual display
■Support guard dog, network wake up, power on boot function
■Support for Windows XP/7/8/10 and Linux operating systems
■Can be widely used in industrial control, rail transit and other industries
■Support for Intel ? 3rd generation Core ? i5 / i3 processors
■Support 7×USB2.0, 2×COM, 1× gigabit network card
■Support VGA+HDMI synchronous/asynchronous dual display
■Support guard dog, network wake up, power on boot function
■Support for Windows XP/7/8/10 and Linux operating systems
■Can be widely used in industrial control, rail transit and other industries
Product specification | |
■+A13:B29 | |
CPU | Intel? 3th Core? i3-3227U 1.9GHz，2M L2，2Cores/4Threads |
Chipset | Intel? HM76 |
Memory | DDR3 1600 2GB（4GB、8GB Optional） |
Storage | 16GB mSATA（8GB、32GB、64GB、128GB、etc Optional） |
Expansion Slot | 1×Mini-PCIe(WIFI、3G/4G Supported) |
Front I/O | |
USB | 3×USB2.0 |
COM | 2（COM2 Pin#9 5V/12V Power Optional） |
PWR Button | 1 |
Rear I/O | |
VGA | 1 |
HDMI | 1 |
USB | 4×USB2.0 |
Audio | 1×Line-out，1×Mic-in |
LAN | 1×RJ45 1000Mbps LAN |
WIFI Antenna | 2 |
DC-IN | 1 |
Mechanical & Environment | |
Dimensions | 230×213.75×44mm |
Power Input | DC 12V |
Colour | Black |
Temperature | Operation:0~45 ℃ Storage:-25~75℃ |
Relative Humidity | Operation:10%~90% Storage:5%~95% |
